PCB and FPC fabrication, component sourcing, SMT and DIP assembly, and functional test — under one roof. One quote, one lead time, one party accountable for defects. No minimum order quantity.

  • IATF 16949
  • ISO 13485
  • ISO 9001
  • IPC-A-610 Class III
A populated printed circuit board, assembled on the SMT line, shown tilted and rotating.
24+SMT lines
40.39MPlacement points / day
6+Test lines
1pcMinimum order
One-stop PCB & PCBA 13 YAMAHA · 4 Panasonic · 7 JUKI 8 × 3D SPI 26 AOI systems IPC-A-610 Class III IATF 16949 ISO 9001 ISO 13485 24 SMT lines · 6 test lines 40.39M points / day From 1 pc
A green rigid circuit board with a polyimide flexible tail folded over it, inside a black housing
01

PCB & FPC fabrication

Rigid, flexible and rigid-flex circuits from 1 to 32 layers, minimum line and space 0.06 mm, on panels up to 650 × 1,100 mm.

  • 1–32 layers
  • 650 × 1,100 mm
A surface-mount line with a solder-paste printer, conveyors and line monitors, with an SMT14 sign overhead
02

SMT assembly

24 SMT lines placing passives from 01005 to 2512 and BGA down to 0.3 mm pitch, with 3D SPI before placement and AOI after reflow.

  • 24 SMT lines
  • 0.3 mm BGA
Workers assembling boards at a through-hole line with fume extractors over the benches
03

DIP & through-hole

Six DIP lines for connectors and through-hole parts, so mixed-technology boards are assembled and soldered without leaving the building.

  • 6 DIP lines
  • Mixed technology
Component tape feeders loaded with reels on a Yamaha pick-and-place machine
04

Component sourcing

Turnkey or consigned. Sharp, Toshiba, STMicroelectronics, Samsung, Infineon, JRC and NEC — plus replacement sourcing for obsolete parts.

  • Turnkey
  • Obsolete parts
An operator reviewing board images on an automated optical inspection station
05

Testing & quality

26 AOI systems, 3D X-ray for hidden joints, six test lines, FAI and BGA rework — with IATF 16949 and ISO 13485 systems behind them.

  • 26 AOI
  • 3D X-ray
Start here

Have Gerbers and a BOM?

An engineer reads both before the quote goes out, and tells you what we would change — before you have paid us anything.

Replywithin 2 hours
Quotewithin 24 hours
Minimum1 pc

Bare board

Board types and substrates we fabricate.

Everything on this list is made on our own line in Bao'an. We do not broker your board out to a third-party fab house and put our name on it — a prototype board leaves in 3–4 days and mass production in 8–16, with an expedited prototype in as little as 24 hours.
